The TrolMaster TS-1 Thermostat Station is engineered to replace traditional thermostats in conventional cool-only HVAC systems. By integrating with the Hydro-X Environmental Control System, it offers precise temperature management for your cultivation environment.

Key Features:

• Seamless Integration: Connects effortlessly with the Hydro-X system, enabling synchronized control over your HVAC units.

• LCD Display: Provides clear and easy-to-read temperature settings and current readings.

• Micro-SD Slot: Facilitates straightforward firmware updates, ensuring your system remains up-to-date.

• Plug & Play Design: Simplifies installation without the need for additional power sources.

• Address Assignment: Supports multiple TS modules, allowing for individualized day and night settings across various HVAC systems.

Specifications:

Specification	Details
Output Voltage	24V
Maximum Current	1A
Working Temperature	32-122°F (0-50°C)
Working Humidity	≤90%
Package Dimensions	160mm (L) x 86mm (W) x 86mm (H)
Weight	0.40 kg



Package Contents:

• 1 x Thermostat Station (TS-1)
• 1 x 16ft RJ12 Cable
• 1 x 4ft RJ12 Cable
• 1 x RJ12 T-Splitter

The TrolMaster TS-1 Thermostat Station enhances your HVAC control capabilities by replacing traditional thermostats, providing precise and efficient temperature management within your Hydro-X system.
